Running Large Language Models (LLMs) Locally on a 24GB GPU (RTX 5090)

Running large language models (LLMs) on local hardware has become increasingly feasible. This report explores the top LLMs that can be deployed on a single high-end GPU (NVIDIA RTX 5090 with 24 GB VRAM) – focusing on open-source models, with notes on a few closed models – and covers their architectures, VRAM requirements, speeds, context lengths, and use cases. We also discuss popular local inference frameworks (like llama.cpp, vLLM, LM Studio, Ollama) and optimization techniques (quantization, RoPE scaling, GGUF format) to maximize performance.

Hardware Considerations: 24 GB VRAM and Model Size

GPU VRAM and Model Parameters: The capacity of your GPU’s VRAM primarily determines which models you can run. LLMs are often categorized by parameter count (e.g. 7B, 13B, 70B for 7 billion, 13 billion, 70 billion parameters). VRAM usage scales roughly linearly with model size and precision: for example, a 7B model in half-precision (FP16) may require ~14 GB VRAM, whereas a 13B model is ~26 GB (too large to fit 24 GB without compression) apxml.com. An RTX 5090 with 24 GB can handle smaller models at full precision or larger models with quantization (compression) apxml.com apxml.com. The RTX 40/50 series GPUs also offer high memory bandwidth and tensor core performance, which improve throughput for lower precision inference apxml.com apxml.com.

Quantization: Quantization reduces memory usage by using lower precision for model weights (and sometimes activations). Common formats include 8-bit (INT8) and 4-bit (INT4) weight compression. For instance, 4-bit quantization cuts memory roughly to one-quarter: a 7B model that needs ~14 GB in FP16 might use only ~4–5 GB in 4-bit form apxml.com. Popular quantization methods are GPTQ (post-training quantization for GPU), bitsandbytes (8-bit loader), and the GGUF/GGML 4-bit quant formats used by llama.cpp apxml.com apxml.com. These enable fitting larger models on 24 GB – with some quality trade-off. Example: LLaMA-2 70B in FP16 needs ~140 GB of memory, but in 4-bit (INT4) it’s about 35 GB medium.com. This still exceeds 24 GB, but with 3-bit mixed-precision quantization (ExLlama), it can be reduced to ~26 GB – just at the edge of a 24 GB GPU medium.com medium.com. Some layers can be kept at higher precision while others are lower, to balance performance and memory medium.com medium.com. In practice, many 70B models require splitting across two 24 GB GPUs or offloading some layers to CPU RAM, but advanced quantization (down to 3-bit or even 2-bit) and partial loading can make single-GPU operation almost possible medium.com medium.com.

Inference Speed: Speed is typically measured in tokens generated per second (tok/s). It depends on model size, quantization level, and the efficiency of the software. A larger model means more computation per token, so throughput drops as model size increases. On an RTX 4090/5090-class GPU, a 7B model might generate on the order of ~100–140 tokens/s, whereas a 30B+ model might do ~30–40 tokens/s under similar conditions news.ycombinator.com. For example, using the optimized exllama GPU backend, users reported ~140 tok/s for a 7B model and ~40 tok/s for a 33B model on a 24 GB GPU news.ycombinator.com. An independent benchmark with the Ollama engine (using 4-bit quantized models) showed LLaMA-2 13B-chat at ~71 tok/s and LLaMA-3.1 8B at ~95 tok/s on a 4090 databasemart.com. In the same test, a 32B model (Qwen-32B) reached ~34 tok/s and a 34B model ~37 tok/s databasemart.com. This illustrates the inverse scaling of speed with size. Quantization can improve speed slightly (by reducing memory bandwidth pressure) but sometimes at the cost of some GPU compute efficiency. The chart below shows an example of running a 32B model on a 24 GB GPU, reaching about 34 tok/s with ~90% VRAM utilization:
